PACKAGE CONTENTS:
Motor, plunge base, fixed base, 1/2” (12.7 mm) collet and 1/4” (6.4 mm) collet sleeve, straight-edge
guide, dust-extraction adaptor (fixed base), dust-extraction adaptor (plunge base), 2 chip shields, collet
wrench, nylon tote, and instruction manual.
KEY PARTS DIAGRAM
No. Description No. Description
1 Motor housing 10 Motor clamp
2 Fixed base 11 Live-tool indicator light
3 Spindle-lock button 12 Micro-adjustment knob
4 Self-releasing collet 13 Plunge-depth locking lever
5 Handle 14 Depth-rod locking knob
6 ON/OFF switch 15 Depth-stop turret
7
Fine-adjustment dial with depth-
indicator ring
16 Dust-extraction adaptor
8 Coarse-adjustment knob 17 Handle
9 Vacuum port 18 Plunge base
KEY PARTS DIAGRAM
1 5
6
7
8
9
10
11
2
3
12
13
14
15
16
17
18
4
NOTICE: Before attempting to use this tool, become familiar with all of its operating features and safety requirements. For
optimum performance and safety, read the following operating instructions carefully before using this product.
