23
PARTS LIST
65 3660399000 Spring 79 5620103000 Screw
66 3550083000 Depth Adjusting Bolt 80 3123344000 Chip Shield
67 3550913000 Depth Stop Bar 81 3700078000 Wave Washer
68 3121634000 Depth Indicator 82 3420387000 Turntable
69 3121639000 Cover 83 5700046000 Steel Ball
70 5660018000 Circlips 84 3660030000 Spring
71 3400189000 Lock Bolt 85 2826747000 Mounting Assembly
72 2826744000 Plunge Frame Assembly 86 3122923000 Base Plate
73 3660254000 Torsion Spring 301 5620353000 Screw
74 5640045000 Bolt 302 3130301000 Vacuum Adaptor
75 3420398000 Plunge Lock Lever 303 3402471000 Wrench
76 5620040000 Screw 304 3123286000 Vacuum Adaptor
77 3123581000 Bellows Seal 305 3550560000 Collet
78 3660166000 Spring 306 2822286000 Parallel Guide
If any parts are missing or damaged, or if you have any questions, please call the toll-free helpline at
1-800-689-9928.
