X30
Page 2-10 2014 MasterCraft Owners Manual • Guide to Individual Models
G U I D E T O I N D I V I D U A L M O D E L S
Length of Boat .........................23’4”
Width Amidship ........................ 102”
Boat Weight ....................4,350 lbs.
Length of Boat w/Platform ..25’7”
Towing Length .........................28’7”
Towing Width ............................ 102”
Fuel Capacity .................60 gallons
Maximum Capacity .........................
................ 16 people or 2,219 lbs.
................Bow: 5 people or 700 lbs.
Storage space is located under:
Observer’s seat, bow seating, aft and wrap-
around seating.
1 = Anchor storage
2 = Bow cleat (where equipped)
3 = Horn
4 = Ballast tank below oor board
5 = Adjustable mirror
6 = Bilge thru-hull outlet
7 = Ballast thru-hull vent
8 = Circuit breaker panel (on kick panel beneath
instrument panel)
9 = Navigation light
10 = Instrument panel (details in Video Display
Gauge section)
11 = Steering wheel
12 = Shift/throttle control
13 = Heated seat (where equipped)
14 = Fire suppression unit manual override
15 = Subwoofer (where equipped)
16 = Cooler (under seat)
17 = Garbage can
18 = Midship cleat
19 = Fuel tank ller
20 = Bilge thru-hull vent
21 = Reversible seating
22 = Engine compartment
23 = Stern cleat
24 = Stern light receptacle (if equipped with tower,
the light will be in center aft of tower)
25 = Molded-in boarding platform
26 = Transom stereo remote (where equipped)
27 = Underwater lights (two, where equipped)
28 = Wake adjustment plate (where equipped)
29 = Automatic re extinguisher
30 = Teak platform (or berglass, where quipped)
31 = Transom drain plug
32 = Transom rail with tow eye
33 = Engine exhaust (each side)
34 = Shower wand & switch (where equipped,
inside compartment)
35 = Freshwater tank (where equipped)
36 = Stern cleat
37 = Ballast thru-hull vent
38 = Ski pylon
39 = Fuel tank ller
40 = Batteries ON-OFF switch (under seat)
41 = Midship cleat
42 = Cockpit table mount (where equipped)
43 = Center drain plug (under inspection plate)
44 = Heated observer seat (where equipped)
45 = Hand-held re extinguisher (beneath
observer seat)
46 = Amp (where equipped)
47 = Batteries (under seat)
48 = Navigation light
49 = Glove box
50 = iPod interface (where equipped)
51 = Stereo remote (on dash)
52 = Bow ller cushion (where equipped)
53 = Bow cleat (where equipped)
