model no. 054-7296-6 | contact us 1-800-689-9928
16
No. Part No. Description No. Part No. Description
1 4810003210 Power Cord and Plug 19 2740099000 Stator
2 3121011000 Cord Guard 20 3402301000 Dust Fan
3 3322657000 Left Housing 21 3421477000 Counterweight
4 4870051000 Switch 22 5650041000 Plain Washer
5 3125792000 Switch Cover 23 3402638000
Bearing Support
Assembly
6 4960316000 Carbon Brush 24 3700090000 Washer
7 2800234000 Brush Holder 25 5620069000 Screw
8 4930004000 Connecter 26 3127058000 Bearing Clamp
9 4860360000 Internal Wire Assembly 27 5690439000 Brake Ring
10 4860302000 Internal Wire Assembly 28 2826903000 Base Pad
11 4860299000 Internal Wire Assembly 29 5620342000 Screw with Washer
12 4930030000 Receptacle 30 3120234000 Cord Anchorage
13 4930008000 Sleeve 31 5610024000 Tapping Screw
14 5690013000 O-ring 32 3322658000 Right Housing
15 2490136000 Nylon String 33 5610106000 Tapping Screw
16 5660187000 C-ring 301 3810300000 Sanding Paper
17 5690268000 O-ring 302 2826581000 Dust Box Assembly
18 2824316000 Rotor Set
If any parts are missing or damaged, or if you have any questions, please call the toll-free helpline at
1-800-689-9928.
PARTS LIST
