14
model no. 054-1332-6 | contact us 1-800-689-9928
COLD WEATHER OPERATION
When the battery pack is very cold, it may “pulse” for the first minute of use to warm itself. Put the
battery pack on the tool and use the tool in a light application. After about a minute, the battery pack
will have warmed itself and will operate normally.
WHEN TO CHARGE THE BATTERY PACK
The Lithium-Ion battery can be charged at any time and will not develop a “memory” when charged
after only a partial discharge. It is not necessary to run down the battery pack charge before
recharging. Remove the battery pack from the tool when it is convenient for you and your job.
1. Use the Fuel Gauge to determine when you need to recharge the battery pack.
2. You can “top-off” your battery pack’s charge before starting a big job or long period of use.
3. Due to Lithium-Ion’s fade-free properties, the only time it is necessary to charge the Lithium- Ion battery pack
is when the pack has reached the end of its charge. To signal the end of charge, power to the tool will drop
quickly. Charge the battery pack as needed.
HOW TO CHARGE THE BATTERY
PACK (fig 1)
1. Charge the Lithium-Ion battery pack with the correct
charger.
2. Align the raised electric contacts on the charging
base with the corresponding slots in the battery
pack, and slide the charging base onto the battery
pack (fig 1).
3. Connect the charger to a power supply.
4. The charger will communicate with the battery pack’s circuitry to evaluate the condition of the battery
pack.
5. The Fuel Gauge LED lights will cycle from right to left during charging. This is part of the normal charging
operation.
6. After charging is complete, the green LED on the charger will be on and the Fuel Gauge LED lights will
turn off. The Fuel Gauge LED lights will not be displayed when the Fuel Gauge button is pressed while the
battery pack is on the charger.
7. The battery pack will fully charge, but will not overcharge, if left on the charger.
OPERATING INSTRUCTIONS
fig 1
NOTE: This Lithium-Ion battery pack is shipped partially charged. Before using it the first time, fully charge the battery pack.
