17
OPERATING INSTRUCTIONS
LED WORKLIGHT
(fig 10)
The LED worklight, located on the base of the
cordless drill/driver, will illuminate when the
variable-speed trigger switch is depressed, and
will automatically turn off for a brief while after
the variable-speed trigger switch is released. This
provides additional light on the surface of the
workpiece for operation in lower light situations.
ELECTRIC BRAKE
To stop the tool, release the variable-speed trigger
switch and allow the chuck to come to a complete stop. The electric brake quickly stops rotation. This
feature engages automatically when you release the variable-speed trigger switch.
MAGNET ON TOP
(fig 11)
The magnet on the top of the cordless drill/driver
allows for convenient temporary storage of screws
and bits.
fig 10
LED
worklight
NOTICE: The worklight is for lighting the immediate work surface and is not intended to be used as a flashlight.
fig 11
Magnet
Bit
