Unpacking (Fig. 1)
Carefully unpack the thickness planer and all of its parts, and compare them against the list
below. Do not discard the carton or any packaging until the thickness planer is completely
assembled.
WARNING:
IF ANY PART IS MISSING OR DAMAGED, DO NOT PLUG THE THICKNESS
PLANER IN UNTIL THE MISSING OR DAMAGED PART IS REPLACED AND ASSEMBLY
IS COMPLETE.
VI. Assembly and adjustments
11
A Planer
B Dust chute
C Cutter head depth adjustment
handle
D Hex screw and washer for cutter
head depth adjustment handle
E Rubber feet (4)
F Spare set of blades
G Knife depth/alignment tool
H Knife alignment wrench
I Hex keys (3)
J Mounting bolts (4)
K Long top plates (2)
L Short top plates (2)
M Long support plates (2)
N Short support plates (2)
O Legs (4)
P Rubber feet (4)
Q Hardware kit
Fig. 1
A
B
C
D
F
K
M
O
N
L
P
Q
G
E
I
J
H
