MasterCraft 55-5503-4 - Replacement Parts

MASTERCRAFT
®
12 1/2" THICKNESS PLANER WITH WORK STAND 55-5503-4
Use only Mastercraft
®
Thickness Planer replacement parts. Use of any other part may cause
damage to the product. Any and all servicing of the thickness planer should be performed by a
qualified service technician.
IX. Replacement parts
23
1 Nut, M6 4
2 Thread rod 6x25 4
3 Flat washer 6 8
4 Spring pin, 3x18 4
5 Jointer 4
6 Nut, M6 8
7 Screw, M6x20 4
8 Stopper (B) 4
9 Extension bar 4
10 Roll pole 2
11 Shaft 2
12 Extension table 2
13 Spring pin, 3x16 4
14 Nut, M5 8
15 Flat washer, 5 41
16 Bar holder 4
17 Hex bolt, M5x16 8
18 Screw, M4x8 12
19 Link block 2
20 Pin, Φ2.5x12 4
21 Rubber feet 4
22 Screw, M8x20 8
23 Hex bolt, M6x25 4
24 Spring washer 8 4
25 Cable clip 1
26 Flat washer 8 4
27 Retainer 10 4
28 Cone gear 4
29 Column 4
30 Guide plate 2
31 Spacer 2
32 Threaded pole (A) 1
33 Key, 4x8 4
34 Block 2
35 Base 1
36 Side cover 2
37 Scale 1
38 Rivet 6x25 4
39 Screw M6x20 3
40 Spring washer 5 18
41 Screw, M5x12 29
42 Knob 2
43 Spring block 4
44 Thread sleeve 1
45 Adjustment nut 2
46 Spacer 4
47 Work table 1
48 Blade 2
49 Blade clamp 2
50 Screw 14
51 Bearing 6203-2RZ 1
52 Retainer 40 1
53 Key, 5x11 1
54 Driven wheel 1
55 Nut, M16x1.5 1
56 Belt 1
57 Dust chute 1
58 Screw, ST6x20 2
59 Body 1
60 C-cover 1
61 Indicator 1
62 Screw, M4x10 4
63 Flat washer 4 17
64 Sprocket wheel 1
65 Motor assembly 1
66 Stop pin 2
67 Sprocket gear 4
68 Washer 3
69 Spring washer 6 6
70 Screw, M6x16 3
71 Crank handle assembly 1
72 Top guard (B) 1
73 Rotation mark 1
74 Screw, M4x20 2
75 Tool box 1
76 Tool box cover 1
77 Screw, M4x8 6
78 Top guard (A) 1
79 Chain 2
80 Side cover 1
81 Nut, M4 2
82 Bushing (A) 3
83 Bushing (B) 1
84 Retainer 37 1
85 Spring (A) 1
86 Bearing 6202-2RZ 1
87 Spring (B) 3
88 Bearing (A) 4
89 Bearing clamp 4
90 Screw, M5x10 4
91 Compression spring (B) 1
92 Roller guide 2
93 Blade shaft 1
94 Thread sleeve (LH) 1
95 Thread pole (B) 1
96 Transport rod 1
97 Bearing (B) 2
98 Anti-dust cover 1
99 Screw, M5x8 6
100 Link block (RH) 2
101 Compression spring (A) 1
102 Brush holder 2
103 Screw, M5x10 2
104 Motor housing 1
105 Stator 1
106 Baffle plate 1
107 Bearing 6200-2Z 1
108 Screw, M5x60 2
109 Armature 1
110 Bearing 6200-2Z 1
111 Gear box cover 1
112 Bearing (C) 2
113 Gear (B) 1
114 Switch 1
115 Shaft (A) 1
116 Power cord 1
117 Cord bushing 1
118 Strain relief 1
119 Screw, ST4.2x12 4
120 Shaft (B) 1
121 Key, 3x7 1
122 Gear (C) 1
123 Bearing (D) 2
124 Sleeve 2
125 Wave washer 4 3
126 Screw, ST5x60 1
127 Screw, ST5x50 3
128 Shaft 1
129 Key, 4x10 1
130 Bearing 1
131 Motor label 1
132 Carbon brush 2
133 Brush cap 2
134 Retainer 16 1
135 Gear (A) 1
136 Bearing 1
137 Gear box 1
138 Sponge pad 1
139 Dust guard 1
140 Current protector 1
141 Plug 4
142 Screw, ST3x8 2
143 Cover 1
144 Nut, M12 1
145 Block 1
146 Screw, M4x12 1
147 Spring washer 4 1
999 Instruction manual (not shown) 1
No. Description Qty No. Description Qty No. Description Qty
