Item Description Qty Item Description Qty
1 Star-head screw 4 40 Right safty guard cover 1
2 Philips Screw with spring
washer
6 41 Carriage bolt 2
3 Base cover 1 42 Star-head screw 4
4 Pc board 1 43 Star-head screw (white) 4
5 Star-head screw 2 44 Left end cap 1
6 Pc board cover 1 45 Wavy washer 1
7 Star-head screw 2 46 Ball bearing 2
8 Star-head Screw 4 47 Stator 1
9 Rubber foot 4 48 Rotor 1
10 Lock washer 2 49 Right end cap 1
11 Capacitor 1 50 Sensor 1
12 Base 1 51 Plate 1
13 Cord clip fixing plate 1 52 Right end cap 1
14 Cord clip 1 53 Lock nut 2
15 Star-head screw 2 54 Flat washer 4
16 Cord & plug 1 55 Eye shield mounting rod 2
17 Left Spark Shield 1 56 Eye shield 2
18 Cord bushing 3 57 Eye shield plate 2
19 Toothed lock washer 2 58 Star-head screw 4
20 Inner hex head set screw 1 59 Right spark shield 1
21 Flange hex nut 5 60 Small carriage bolt 2
22 Wire fix ring 1 61 Star-head screw (white) 3
23 Ring for brush wheel 1 62 Right safety guard 1
24 Star-head screw 1 63 Right fixed work rest 1
25 Speed controller 1 64 Right movable work rest 1
26 Switch plate 1 65 Hex nut (white) 1
27 Star-head screw 4 66 Locking knob 2
28 Speed control knob 1 67 Big flat washer (white) 2
29 Switch guard 1 68 Left safety guard cover 1
30 Star-head screw 2 69 Left safety guard 1
31 Switch 1 70 Wheel 60# 1
32 Coolant tray 1 71 Left fixed work rest 1
33 Flange hex nut 4 72 Left movable work rest 1
34 Lock nut 2 73 Lamp holder (40 w) 1
35 Coolant tray clip 1 74 Flat washer 1
36 Flange 4 75 Hex nut (white) 1
37 Wheel 1 76 Star-head screw 2
38 Rubber cover 1 77 Hex nut 8
39 Hex nut 1
PARTS LIST
model no. 055-3503-6 | contact us 1-800-689-9928
WARRANTY
23
5-Year Limited Warranty
This Mastercraft Maximum product is guaranteed for a period of 5 years
from the date of original retail purchase against defects in workmanship
and materials, except for the following component:
Component A: Accessories, which are guaranteed for a period of 1-year
from the date of original retail purchase against defects in workmanship and materials.
Subject to the conditions and limitations described below, this product, if returned to us
with proof of purchase within the stated warranty period and if covered under this
warranty, will be repaired or replaced (with the same model, or one of equal value or
costs of labour relating thereto.
These warranties are subject to the following conditions and limitations:
a) a bill of sale verifying the purchase and purchase date must be provided;
b) this warranty will not apply to any product or part thereof which is worn or broken or
which has become inoperative due to abuse, misuse, accidental damage, neglect or
lack of proper installation, operation or maintenance (as outlined in the applicable
owner’s manual or operating instructions) or which is being used for industrial,
professional, commercial or rental purposes;
c) this warranty will not apply to normal wear and tear or to expendable parts or
accessories that may be supplied with the product that are expected to become
inoperative or unusable after a seasonable period of use;
d) this warranty will not apply to routine maintenance and consumable items such as,
tune-ups or adjustments;
e) this warranty will not apply where damage is caused by repairs made or attempted by
others (i.e. persons not authorized by the manufacturer);
f) this warranty will not apply to any product that was sold to the original purchaser as a
g) this warranty will not apply to any product or part thereof if any part from another
manufacturer is installed therein or any repairs or alterations have been made or
attempted by unauthorized persons;
not limited to, scratches, dents, paint chips, or to any corrosion or discolouring by
heat, abrasive and chemical cleaners; and
of another company, which shall be covered under the product manufacturer’s
warranty, if any.
