MasterCraft MAXIMUM 055-3503-6 User Manual

10
KEY PARTS DIAGRAM
NO
FFO
L
H
1
2
3
4
5
6
7
8
910
11
12
13
No. Description Qty.
1
Work light On/Off switch 1
2
Work light 1
3
Eye shield support 1
4
Spark guard 1
5
Eye shield 1
6
36-grit grinding wheel 1
7
Right tool rest 1
8
Variable speed control 1
9
Coolant tray 1
10
On/Off switch 1
11
Mounting hole 1
12
Left tool rest 1
13
60-grit grinding wheel 1
model no. 055-3503-6 | contact us 1-800-689-9928
11
PACKAGE CONTENTS
Package contents
No. Description Qty.
1
Bench grinder 1
2
Tool rest mounting bracket 1
3
Tool rest 1
4
Locking knob/flat washer
Locking nut knob/flat washer
Carriage bolt
2
5
Spark guards 1
6
Star-head screw
Lock washer
Flat washer
4
7
Right/Left eye shields 1
8
Coolant tray 1
ON
OFF
L
H
1
2
3
4
5 6
7
8

MasterCraft MAXIMUM 055-3503-6 Specifications

General

Brand	MasterCraft
Model	MAXIMUM 055-3503-6
Category	Grinder
Language	English
