INSTALLING NO-MAR TIP
When driving nails into soft materials, the
nail gripping jaws may mar the workpiece.
To protect the soft material you should
install the no-mar tip.
To install the no-mar tip, slide the no-mar
tip (1) over the nail gripping jaws (2) and
over the rear of the nail gripping jaws (3)
(Fig. 4).
NOTES:
a) Make sure the rectangular openings
(4) on both sides of the no-mar tip are
fully engaged with the matching
rectangular rear portions (3) of the nail
gripping jaws (Fig. 5). This will ensure
the no-mar tip is installed correctly and
will be held in place during operation
of the tool.
b) When the no-mar tip is installed, the
nailer will drive the head of the nail
approximately 2 mm less distance
than when the no-mar tip is NOT
installed.
To remove the no-mar tip, carefully pull
outwards on the sides of the no-mar tip
and slide it off the nail gripping jaws.
