MasterCraft MCPAC12KHM User Manual

7
PARTS IDENTIFICATION
a. Control Panel
b. Horizontal Louver Blade
c. Panel
d. Caster
e. Upper Air Filter
(behind the grille)
f. Handle (both sides)
g. Upper Air Intake
h. Drain Outlet
i. Air Outlet
j. Power Plug Socket
k. Power Cord Outlet
l. Lower Air Filter
(behind the grille)
m. Lower Air Intake
n. Power Cord Buckle
o. Bottom Tray Drain Outlet
p. Remote Control
NOTE: Exhaust hose and other installation accessories should not be discarded.
Figure 2
p
e
f
g
h
i
j
k
l
o
n
m
a
b
c
d f
Front Rear

MasterCraft MCPAC12KHM Specifications

General

Brand	MasterCraft
Model	MCPAC12KHM
Category	Air Conditioner
Language	English
