2017 OWNERS MANUAL / 308
Location
Cable attachments are located in the glove box or observer seat-
ing area.
Operation
Connecting a GoPro camera to the MasterCraft 7” video screen
for the first time requires a few initial steps that make it simple to
display live action in the future.
Step 1: Pair a GoPro Camera (not supplied) with an Apple Device
(not supplied)
a. Download and install the free GoPro app from the iTunes store
(one time only)
b. Turn on the Apple device Wi-Fi from the list of available Wi-Fi
connections
c. Turn on the GoPro camera
d. Open the GoPro app on the Apple device
e. Go to Settings in the GoPro app and follow the on-screen
prompts to connect the GoPro camera to the Apple device
Step 2: Connect Apple Device to Boat HDMI Adapter
a. Attach the Apple Lightning to USB Cable (not supplied) to the
Apple device
b. Take the Apple device to the glovebox and attach the USB end of
the Apple Lightning to USB Cable to the supplied Lightning to HDMI
Adapter
c. Plug the Lightning to HDMI Adapter into the HDMI port on the
HDMI/USB panel that is mounted in the glovebox
d. Plug the USB end of the Lightning to HDMI Adapter into the USB
port on the HDMI/USB panel that is mounted in the glovebox
Step 3: 7” Screen Set-Up
a. Push the Video button on the 7” screen
b. Select Tower as the Video source.
NOTE: The following items are user supplied and not included with a
MasterCraft boat
1. Apple device, only models with Lightning connector such as
iPhone 5, and newer iPad/iPad Mini
2. Apple Lightning to USB cable
3. GoPro camera, only models with Wi-Fi capability, such as Hero3
with Wi-Fi backpack or Hero4
