2017 OWNERS MANUAL / 140
Track Manager
The advantage to using the Track Manager on the 4.5” touch screen is
that the results can be immediately seen on the map displayed on the
7” touch screen. The Track Manager can be closed by touching [X].
From this screen, the following can be accomplished:
• Track name edited;
• Tracks shown or hidden;
• Tracks deleted;
• Single track;
• All tracks.
NOTE: For more information on managing tracks, see GPS Utilities
under the Settings Menu.
Depth and Position Set-up
Use the Depth and Position Set-up on the 4.5” touch screen and
the results can be immediately seen on the map displayed on the 7”
touch screen.
For example, modify the Depth Contour or the Safety Contour, the
contours are immediately shown on the 7” touch screen. The Depth
and Position Setup screen can be closed by touching [X].
Chart and Time Set-up
The advantage to using the Chart and Time Set-up on the 4.5”
touchscreen is that the results can be immediately seen on the
map displayed on the 7” touch screen. For example, if [SHOW GRID]
is turned on, the grid lines are immediately shown on the 7” touch
screen map The Chart and Time Set-up screen can be closed by
touching [X].
NOTE: For more information on the functions of the Chart and Time
Setup screen, see GPS Utilities under Menu Options.
GPS Status
The GPS Status screen on the 4.5” touch screen is identical to the
GPS Status screen on the 7” touch screen. It shows the status of
detectable satellites and their locations.
Track Menu
Touch menu to:
• Find the current position on the map;
• Create waypoints;
• Clear track;
• Save track.
