14
model no. SC20BST | contact us 1-800-689-9928
TO ATTACH BATTERY PACK
(fig 8)
1. Make sure that the switch is in the OFF position.
2. Align the raised portion on the battery pack with
the grooves on the bottom of the tool, and then
slide the battery pack onto the tool as shown.
3. Ensure that the battery-release button on the
battery pack snaps into place and the battery pack
is secured to the tool before beginning operation.
TO DETACH THE BATTERY PACK
(fig 8)
1. Ensure that the switch is in the OFF position.
2. Depress the battery-release button located on the front of the battery pack to release the battery pack.
3. Pull rearward on the battery pack to remove it from the tool.
•
fig 8
WARNING!
• To avoid the possibility of accidental starting, always take care not to activate the on/off switch when you are attaching the
battery pack or performing other adjustments to the tool.
NOTICE: When placing a battery pack on the tool, be sure that the raised rib on the battery pack aligns with the groove
on the cordless trimmer and the latches snap into place properly. Improper assembly of the battery pack can cause damage to
internal components.
OPERATING INSTRUCTIONS
Battery-release
button
