2-1 Pump Drives Operating Manual Masterflex
Section 2 Installation and Setup
WARNINGS: Tubing breakage may result in fluid being sprayed
from pump. Use appropriate measures to protect operator and
equipment.
Turn Pump System off before removing or installing tubing.
Fingers or loose clothing could get caught in drive mechanism.
1. Mount Pump Head and load tubing. (See Pump Head manual.)
CAUTION: To avoid electrical shock, the power cord
protective grounding conductor must be connected to ground. Not
for operation in wet locations as defined by EN61010-1.
2.
Check that the jumper is installed in the external start/stop connector
.
The drive will not run unless this is installed See figure 2-3.
3. Adjust flow rate with the 1-turn potentiometer speed control.
CAUTION: When changing flow direction, allow the pump to
come to a complete stop before starting again. Failure to do so
could cause permanent damage to the motor.
Setup and Drive
Operation
