Page 9
GENERAL ASSEMBLY INSTRUCTIONS
12. For wet vacuum cleaning, install the supplied
foam wet filter. (fig. 13) For filter installation
instructions, refer to page 18.
Fig. 13
13. Place the power head back on the collection
tank, aligning the top section with the
latches, and snap into place. (fig. 14)
Fig. 14
14. Insert the locking end of the hose into the
vacuum port and turn to lock into place.
(fig. 15)
Fig. 15
15. Choose the desired accessories and push
onto the suction tube. (fig. 16)
Fig. 16
POLARIZED PLUG
To reduce the risk of electrical shock, this
appliance has a polarized plug (one blade wider
than the other). This plug will fit in a polarized
outlet only one way. If the plug does not fit fully
in the outlet, reverse the plug. If it still does not
fit, contact a qualified electrician to install the
proper outlet. Do not change the plug in any
way. Double insulation eliminates the need
for the three wire grounded power cord and
grounded power supply system.
