Page 7
GENERAL ASSEMBLY INSTRUCTIONS
A Philips head screwdriver is required.
WARNING:
DO NOT PLUG POWER
CORD INTO POWER OUTLET, MAKE
SURE PLUG IS DISCONNECTED BEFORE
ASSEMBLING THE WET/DRY VAC.
UNPACKING YOUR WET/DRY VACUUM &
GENERAL ASSEMBLY
1. Verify that the power cord is disconnected
from the outlet. (fig. 1)
Fig. 1
2. Undo the latches. (fig. 2)
Fig. 2
1
2
3. Lift the power head off the collection tank.
(fig. 3)
Fig. 3
4. Remove the contents from inside the
collection tank. Make sure you have all
contents as listed on page 5. (fig. 4)
Fig. 4
5. Turn the collection tank upside down and
insert the two caster feet into the front
slots on the collection tank and tighten with
supplied screws. Verify that the casters
are mounted correctly. Do not over-tighten
screws. (fig. 5)
Fig. 5
6. Insert the rear wheel housing (W) and
secure with the supplied screws. Verify that
they are mounted correctly. Do not over-
tighten screws. (fig. 6)
Fig. 6
To Next Page
