Page 11
OPERATING INSTRUCTIONS: DRY
VACUUMING
5. Insert the locking end of the hose into the
vacuum port and lock in place. Push the
required attachment onto the free end of
the hose or extension. (fig. 6)
Fig. 6
6. Plug the power cord into the outlet. (fig.7)
Fig. 7
7. Turn the motor on by lipping the switch to
the ‘I’ ON position. (fig. 8)
Fig. 8
8. Once you have completed vacuuming, flip
the switch to the ‘O’ OFF position and unplug
the power cord from the outlet.
O = OFF I = ON
DO NOT USE THE CARTRIDGE FILTER FOR
LIQUID VACUUMING.
DRY VACUUM OPERATION
