19
WARNING: When servicing, use only original equipment replacement parts. The use of any
other parts may create a safety hazard or cause damage to the circular saw.
Any attempt to repair or replace electrical parts on this circular saw may create a safety hazard unless
repairs are performed by a qualified technician. For more information, call the Toll-free Helpline, at
1-866-349-8665 Friday from 9am to 5pm Eastern Standard Time.
Always order by PART NUMBER, not by key number.
Key #
Part #
Part Name
Quantity
1
4050050006
Hex screw M8X16
1
2
2040210039
Outer flange
1
3
2040210003
Inner flange
1
4
4100020009
Circlip for shaft Φ36
1
5
4020010001
M4×8 screw
1
6
4040030001
Spring washer 4mm
3
7
2030030231
Lower guard lever
1
8
2020080040
Lower guard
1
9
2050050043
Lower guard spring
1
10
4020020005
Screw M5×12
4
11
2020150070
Gear cover
1
12
4010010081
Bearing 6201 2RS
1
13
2040040090
Output gear
1
14
4120010003
Flat key
1
15
2040080031
Output gear
1
16
4040020002
Spring washer Φ12
1
17
4100020008
Circlip for shaft Φ12
1
18
4010020003
Needle bearing HK0810
1
19
4030010096
Tapping screw 4×12
11
20
4020080007
Hex head screw M6×16
1
21
3140090020
Rubber cover for locking bolt
1
22
2020020035
Gear housing
1
23
2050040051
Spindle lock spring
1
24
2030250013
Spindle lock
1
25
2030160122
Spindle lock plate
1
26
4020010006
Screw M4×12
2
27
3140070020
Spindle lock cover
1
28
3150050080
Exhaust air deflector
1
29
4010010055
Bearing 6001 2RS
1
30
1010120014
Motor rotor
1
31
4010010014
Bearing 629 2RS
1
32
3140040012
629 Bearing sleeve
1
33
3150050074
Air deflector
1
34
4030010124
Tapping screw 5×45
2
35
1020120014
Motor stator
1
36
4030010034
Tapping screw 3×16
5
37
3160060060
Lamp cover
1
38
1220040022
Lamp LED
1
39
3011120009
Motor housing
1
40
1230030012
Carbon brush box
2
!
PARTS LIST
