To prevent SERIOUS INJURY:
• DO NOT connect power until instructed.
• Keep hands and fingers clear from sprocket during
operation.
• Wear gloves when installing chain/belt and cable.
• Keep hands and fingers away from joints and
possible sharp edges.
WARNING
masterforceopeners.com Customer Service: 1-877-436-4402 7
Connect the Trolley Sha to the Trolley Sha Connector on the belt, using the Master Link Set.
Slide the Trolley Sha into the Trolley until a “click” is heard when they are connected and locked.
With the trolley positioned against the screwdriver, pull the remaining belt straight along the rail
and engage belt teeth around the sprocket. (Make sure the belt is not twisted around the rail)
To Next Page
