Page 17
EXPLODED VIEW
ITEM NO. PART NO. DESCRIPTION QTY
1 R0201592-00 Impeller assembly 1
2 R0200650-00 Scraper Kit 1
3 R0201593-00 Wheel Assembly 1
4 R0201594-00 Chute Deector Assembly 1
5 R0200908-00 Quick-Release Lever Assembly 1
6 R0201595-00 Knob 1
7 R0200654-00 PCB board 1
8 R0200655-00 Skid plates 1
