SAFETY INSTRUCTIONS
Page 7
• Bevel Lock Lever: The bevel lock lever securely locks
the saw head at 0°, 45°, and 22.5° bevel angles.
• Mitre Guide: The easy-to-read indicator on the mitre guide
shows the exact angle for a mitre cut with detents at 0°,
22.5° and 45°.
• ON/OFF Switch - This tile saw has an easy-access power
switch located on the tile saw arm.
• Table - The table allows the user to slide the workpiece
into the tile saw blade for accurate cuts.
• Water Pump: The water pump provides water to the tile
saw blade or cleaning nozzle.
• Water Tray: Using the water pump and water tray together
keeps water circulating to the tile saw eliminating the need
for frequent water changes.
• Toggle Table Stop: This allows the table to be removed
if needed. Lift the stop and turn it to lock/unlock. If the
slot is aligned with table, the table can be removed. If the
slot is turned sideways, the table is locked into the tile saw.
• Table Lock Lever: To lock the table in place, line up this
lever’s pin with the hole in the rail, and press the lever
towards the rail. Pull out on the lever to unlock the table.
• Tool Storage: The arbour nut wrench and hex key are
conveniently stored on the back of the tile saw arm.
Be sure extension cords are properly wired and in good
condition. Always replace a damaged extension cord
or have it repaired by a qualied technician before using it.
Protect extension cords from sharp objects, excessive heat,
and damp or wet areas.
WARNING: Keep the extension cord clear of the
working area. Position the cord so that it will not get caught
on lumber, tools, or other obstructions while you are working
with a tile saw. Failure to do so can result in serious
personal injury.
WARNING: Check extension cords before each
use. If damaged replace immediately. Never use tile saw with
a damaged cord since touching the damaged area could
cause electrical shock resulting in serious injury.
WARNING: Do not use diamond tile saw blade
rated less than the speed of this tile saw. Failure to heed
this warning could result in personal injury.
WARNING: To avoid electrical hazards, re hazards,
or damage to the tile saw, use proper circuit protection.
Use a separate electrical circuit for power tools. This circuit
should be protected with a time delayed fuse. Before
connecting the tile saw to the power line, make sure the
switch is in the OFF position and the electric current is rated
the same as the current stamped on the motor’s nameplate.
Running at a lower voltage will damage the motor.
GLOSSARY OF TERMS
The safe use of this tile saw requires an understanding of
the information on the tile saw from this operator’s manual
as well as a knowledge of the project you are attempting.
Before use of this tile saw, familiarize yourself with all
operating features and safety rules.
• Saw Blade: Use only 10 in. diamond tile saw blade.
