ORDERING INFORMATION
EN / Chargemaster1 12/35-3, 12/50-3, 24/20-3 & 24/30-3 / August 2009 27
9 ORDERING INFORMATION
9.1 MASTERBUS INSTALLATION COMPONENTS
Part number Description
77040000 MasterBus terminating device
77040020 MasterBus connection cable (UTP patch cable), 0,2m / 0.6ft
77040050 MasterBus connection cable (UTP patch cable), 0,5m / 1.6ft
77040100 MasterBus connection cable (UTP patch cable), 1,0m / 3.3ft
77040300 MasterBus connection cable (UTP patch cable), 3,0m / 10ft
77040600 MasterBus connection cable (UTP patch cable), 6,0m / 20ft
77041000 MasterBus connection cable (UTP patch cable), 10m / 33ft
77041500 MasterBus connection cable (UTP patch cable), 15m / 49ft
77042500 MasterBus connection cable (UTP patch cable), 25m / 82ft
77050100 100m / 330ft MasterBus cable (UTP cable)
77050200 50 pcs. modular jacks
77050000 Complete set to assemble UTP patch cables. Delivery includes: 100m / 330ft UTP cable, 50 pcs. modular
jacks and crimping tool
77030100 MasterConnect USB interface, required as interface between your PC and the MasterBus when using
MasterAdjust software.
77010100 MasterView Classic, Mastervision compatible display to control and monitor all MasterBus products
77010300 MasterView Easy, Touch screen to control and monitor all MasterBus products
77010400 MasterView System, Full-colour touch screen to control and monitor all MasterBus products
77020100 MasterShunt 500, DC-distribution module for exact readout of battery voltage, charge / discharge current,
and state of charge on the display of the ChargeMaster. continuous rating: 250A, peak current: 500A
9.2 MISCELLANEOUS
Part number Description
6384003200 Industrial DC fuse 32A DIN 00
6384004000 Industrial DC fuse 40A DIN 00
6384006300 Industrial DC fuse 63A DIN 00
6381001000 Fuse base DIN 00 (max. 160A)
79009006 Battery switch 250A with knob
79009005 Battery switch 250A with key
6387000600 Double pole automatic circuit breaker DPN 6A-B, 1P+N
6387001000 Double pole automatic circuit breaker DPN 10A-B, 1P+N
6387001600 Double pole automatic circuit breaker DPN 16A-B, 1P+N
6385401610 Double pole automatic circuit breaker and earth leakage switch DPN VIGI 16A / B / 16mA, 1P + N
41500500* Battery temperature sensor, incl. 6 meter / 19 ft cable
* standard included with the delivery of the Chargemaster
Mastervolt can offer a wide range of products for your electrical installation, including an extended program of components for
your MasterBus network, both AGM and gel batteries, shore power connections, DC distribution kits and many more.
See our website www.mastervolt.com for an extensive overview of all our products.
