Mastervolt EasyView 5

EasyView 5 -
User and Installation Manual
29
10 Specifications
10.1 Technical specifications
EasyView 5
Product code 77010310
Weight 0.36kg
0.79lbs
Dimensions 113 x 127 x 43 mm
4.4 x 5.0 x 1.7 inch
Display size 109 mm
4.3 inch
Display languages EN/NL/DE/ES/IT/FR/FI/SV/NO/DA/RU
IP degree IP67 front,
IP23 back
Power supply MasterBus / 12V/24V input
Power consumption Sleep mode ~ 0.9W,
Normal mode ~ 1.6W
10.2 Dimensions
135
117
132
90
8
Ø
6
Ø 10
60
Front cover
Back, with wall box
