EasyView 5 -
User and Installation Manual
1 Product description
The Mastervolt EasyView 5 is a 4.3” touch display that allows the user to monitor, configure and
operate all connected devices in a MasterBus network.
1.1 Parts
1 Front cover*
2 Display panel
3 Top cover
4 Seal**
5 Wall box
6 Bottom cover
* Always use the front cover when the EasyView 5 display needs to be protected from damage or
sunlight.
** Always use the seal when the EasyView 5 display needs to be protected from water, moist and
dust.
