Mastervolt EasyView 5

EasyView 5 -
User and Installation Manual
9
4 Installation instructions
The EasyView 5 offers three mounting options:
• Panel mounting onto the wall box - see section 4.1
• Flush mounting in an 82 x 113 mm hole - see separate instruction sheet with saw template
• Clamp mounting in a hole > 82 x 113 mm - see section 4.2
4.1 Panel mounting
PH2
3mm
