IVO Smart Appendix A 17
ACCESSORIES & REMOTES
Article no description
70404100 basic remote control LED’s
70403050 standard remote contol LED’s current control
-- advanced remote control display with owner’s settings
41500500 IVO Smart temperature sensor
-- IVO Smart 12/50 cable set
-- IVO Smart remote cable set
21705000 Adjustment Interface
-- Smart alarm control box
SERVICE INFORMATION
Article no description
-- sub assembly, main PCB board
-- complete aluminium heatsink
-- cover module
-- connection module
-- front indicator module
-- installation blocks
OPERATING PRINCIPLE
Fully automatic power factor corrected switch mode battery charger, suitable as power supply using a separate non-isolated
pre regulator boost converter for power factor correction, followed by a double forward converter controlled by a combination
of analogue hardware and microprocessor control.
DATA SHEETS
IVO Smart 12/50-2 battery charger. Main PCB of the IVO Smart 12/50-2.
Adjustment Interface,
art. no 21705000.
The below mentioned data can be
adjusted with this digital instrument:
• DC input voltage range (DC low,
DC high)
• adjustment charge voltage (e.g.
traction)
• ‘return’ Amps
