Mastervolt IVO Smart 24/15-3

SPECIFICATIONS IVO SMART
Model IVO Smart 12/35-3 IVO Smart 12/50-3 IVO Smart 24/15-3
Article no. 43013500 43015000 43021530
DC
Charge voltage BULK (25°C) 14.40VDC 14.40VDC 28.80VDC
Charge voltage ABSORPTION (25°C) 14.25VDC 14.25VDC 28.50VDC
Charge voltage FLOAT (Wet; 25°C) 13.25VDC 13.25VDC 26.50VDC
Charge voltage FLOAT (Gel; 25°C) 13.80VDC 13.80VDC 27.60VDC
Total charge current 35A 50A 15A
DC consumption with connected battery <10mA <10mA <5mA
Number of outlets 2 main outputs + 1 slave 3A
Charge characteristics IUoUo / 3 stage / automatic / DIN 41772
Absorption time, reduced output Maximal 6 hours (adjustable); minimal 15 minutes
Temperature compensation 30mV/°C 30mV/°C 60mV/°C
Voltage compensation Auto sense
Recommended DC fuse (Main) 50A-T 80A-T 25A-T
Recommended DC fuse (Slave) 5A-T 5A-T 5A-T
Recommended Wire size < 1.5m 6mm²/AWG9 10mm²/AWG7 4mm²/AWG11
Recommended Wire size > 1.5m 10mm²/AWG7 16mm²/AWG5 6mm²/AWG9
Recommended battery capacity 70~250Ah 100~350Ah 30~125Ah
AC
Input voltage range 180~250VAC (90~140VAC)
Frequency 50/60Hz
Full load consumption (230VAC) 550VA 800VA 480VA
AC cable 3x0.75 mm²
Power factor / cos phi 0.99
General
Ambient operating temperature Guaranteed operation: 0°C to 60°C / 32° F to 140° F (derating above 40°C /
104°F, 5% per °C); in practice: -20°C to 60°C / -4°F to 140°F.
Storage temperature -25°C to 85°C / -13°F to 185°F
Operating humidity 95% max., non-condensing
Efficiency 90% (at nominal input voltage)
Cooling Variofan ‘low noise’ <54dBA
Protections
Short circuiting Yes
Over heating Limited power by temperature sense circuit
Protection degree Horizontally mounted: IP21, vertically mounted: IP20
Options
Communication Quasi RS232, modular RJ12 connection, to alter set points and to change
characteristics (optional interface required) or to connect a temperature sensor
and/or remote panel.
Suitable as power supply without battery Yes, in the Forced float mode.
Mechanical
Connections input/output Screw terminals, maximum wire size 25 mm² / AWG 3
Dimensions (HxWxD) 313 x 187 x 82 mm; 12.3 x 7.4 x 3.2 inch
Mounting holes Diameter 5mm
Weight 3.4 kg / 7.5 lbs
Cabinet Anodized aluminium, strapton ABS blend, blue RAL 5021
Directives: - Generic emission and disturbances standard: EN 55014-1:1993
- Generic harmonic current emissions: EN61000-3-3:1995
- Generic & safety accreditations immunity standard: EN55014-2: 1997
- Electrostatic discharge : EN61000-4-2:1995
- Electrical fast transients: EN61000-4-4:1995
- Surge transient: EN61000-4-5:1995
- Conducted radio frequency disturbances: EN61000-4-6:1996
- Voltage dips: EN61000-4-11:1994
Set points software Default setting Set points software Default setting
Max. bulk/abs time 360min. Gel voltage setting 550mV
Return amps 2/16 of I-max Diode compensation setting 600mV
Abs voltage 14.25/28.50VDC DC alarm voltage 12.50/25.00VDC
Float voltage 13.25/26.50VDC DC alarm delay 30s
Forced to float 13.80/27.60VDC
