OVERALL PICTURE
1 AC mains cable 8 Remove jumper for force float
2 Positive battery terminal #1 9
Remove jumper for gel/AGM/spiral
setting
3 Positive battery terminal #2 10
Remove jumper for diode
compensation
4 Negative battery terminal 11 LED Bulk charge
5 Slave battery terminal 12 LED Absorption charge
6 Digital modular jack 13 LED Float charge
7 Analogue modular jack
Figure 4: Overall picture
2
3
4
13
12
11
1
5
6
7
8
9
10
