Mastervolt Whisper 3.5 3000 RPM

INFORMATION
12 May 2006 / WHISPER 3,5 / EN
2.5.12 Technical data
GENERAL
Model WHISPER 3,5
RPM 3000
Alternator water cooled, synchronous
Engine Kubota diesel, model OC60 (Japan)
Number of cylinders 1
Displacement 276 cm3
Bore X stroke 72x68 mm
Combustion air consumption 0,38 m3/min.. at nominal RPM
Continuous power engine 3 kW nett.
Cooling system Indirect cooling by raw water.
Cooling water pump pto driven Mastervolt self priming impeller pump, type K
Fuel lift pump engine electric pump (12 V DC), additional pump available upon request
Starting battery (optional) 55-90 Ah
Fuel consumption 0.7-1.4 litre/hour, load dependent
Control Digital Diesel Control including automatic start/stop
ELECTRICAL SPECIFICATIONS
Output voltage 230V 50 Hz alternating current (AC) single phase
Output rating 3,6 KVA cos phi = 0,8; 3 KVA = 3 kW cos phi = 1
Voltage tolerance ± 5%
Frequency tolerance ± 5%
Alternator brushless, two pole, synchronous
MECHANICAL SPECIFICATIONS
Supply includes generating set, built into tugged GRP sound shield with steel base frame, mounted
on rubber anti vibration mounts
Dimensions hxwxd 500x505x405 mm
Colour top white, bottom green
Weight 97 kg including sound shield
Max. installation angle 25 degrees
Standard supplies Digital Diesel Control, remote panel (15 m cable)
Optional mobile (vehicle) version, non earth return, spare part kits
