Mastervolt WHISPER 3,5 Installation Manual

July 2005 / MOBILE WHISPER 3,5 / EN 15
INSTALLATION SPECIFICATIONS
Warnings:
In all situations the transfer switches
between shore, inverter and generator
should switch both neutral and L1. Of
course this is the case when using a
Mastervolt Masterswitch
3 INSTALLATION SPECIFICATIONS
3.1 TECHNICAL DATA
Article no 50900520
Dimensions wxdxh. 505x400x500 mm
Weight 97 kg including sound shield
Max. operation angle 25°
Remote panel 15 m cable, indicating: Digital Diesel Control system
Battery capacity min. 12V, 55 Ah
Fuel consumption 0,7-1,5 l/hr, load dependent
Lift fuel pump electric driven 12 V DC, max. lift 1 m
Cooling radiator cooling
Cooling pump raw water Mastervolt self priming impeller pump, PTO driven, type K
Crank case lube oil capacity, 1.3 litre + 0.7 oil cooler, total 2 litre
Alternator synchronous brushless, maintenance free water cooled
Voltage regulation capacitor
Output power 3 kW, 230V/50 Hz at power factor cos phi =1 including the power to drive the
electric radiator cooling fan
Battery charger additional 12V winding including regulator (6 Amps)
