3. Product specification
3.1 Hardware Specification
Feature Description
CPU NXP MCIMX6G2CVM05AB, 528MHz, Arm Cortex-A7
Memory 256MB DDR3 RAM/ 256MB NAND FLASH
Storage Memory Optional SSD up to 32GB or industrial SD-Card
LoRa Radio Two independent radio channels
SX1302 chipsets, 16 frequency channels
SF5-SF12, 27dBm output power
8 x 8 channels LoRa packet detectors per radio channel
Supports EU868, US915, AS920, AS923, AU915, KR920, IN865 regions
WiFi 2.412GHz – 2.484GHz, IEEE 802 Part 11b/g/n (802.11b/g/n)
GPS UBlox Max 7Q GNSS receiver with additional LNA
Ethernet RJ45 10/100 Mbit LAN with 24V POE
Console through USB-C as virtual COM port
LEDs RGB LED status indicator
Interface USB-C with PD for console UART and Power
USB-A 2.0 Host
Reset Button
Internal Sensors 3-Axis Accelerometer
Pressure Sensor
Temperature Sensors
Voltage and Current monitoring
Antenna interface 4x SMA connectors, waterproof
Power Supply 24V DC passive PoE or USB-C PD rev 2.0 up to 22V
Power Consumption 3.5W in average, peak 6W
Operating Temperature -40
◦
C to 85
◦
C
