3.3 LoRa Radio specification 15
Feature Description
Enclosure ASA plastic, anti-UV
Size (without antennas) 101 x 226 x 73mm
Weight 0.4kg
Installation method Pole or Wall mounting
Table 3.1: Key hardware specifications.
3.2 WiFi specification
Feature Description
Chipset Broadcom 43362
WLAN Standards IEEE 802 Part 11b/g/n (802.11b/g/n)
Antenna Port Support Single Antenna for WiFi
Frequency Band 2.412 GHz – 2.484 GHz
Number channels 14
Modulation OFDM, DSSS (Direct Sequence Spread Spectrum),
DBPSK, DQPSK, CCK , 16QAM, 64QAM
Supported rates 1,2, 5.5,11,6,9,12,24,36,48,54 Mbps
Maximum receive level -10dBm (with PER < 8%)
Output Power 17 dBm +2/-2 dBm for 1, 2, 5.5, 11Mbps
14 dBm +2/-2 dBm for 6, 9, 12, 18, 24, 36, 48, 54 Mbps
12 dBm +2/-2 dBm for 11n (HT20)
Internal Antenna Gain 2 dBi (Typical)
Internal Antenna Polarity Linear
Antenna Azimuth Beamwidth Omni-directional
PER <8%, Rx Sensitivity @ 1 Mbps -94 dBm Typical
PER <8%, Rx Sensitivity @ 11 Mbps -87 dBm Typical
PER <10%, Rx Sensitivity @ 54 Mbps -73 dBm Typical
PER <10%, Rx Sensitivity @ MCS0 -86 dBm Typical
PER <10%, Rx Sensitivity @ MCS7 -70 dBm Typical
Table 3.2: Key WiFi specification.
3.3 LoRa Radio specification
Feature Description
Chipset 2x Semtech SX1302
Operating Frequency MX1901 EU868, IN865
Operating Frequency MX1902 US915, AS923, AU915, KR920
Frequencies channels 8 LoRa
R
channels multi-data rates (SF5 - SF12 / 125 kHz) +
per SX1302 chipset + 2 mono-data rate (LoRa
R
250 / 500 kHz and FSK 50 kbps)
Antenna Port 2x SMA
Transmit Power 27 dBm
