§2 Technology Parameters
§2.1 Parameters
Models
Parameters
PCA48 PFC
Input power 110-220VAC, Single-Phase，50/60Hz
Rated input current（A）
21(220V)
31(110V)
Rated input power（KW）
4.7(220V)
3.4(110V)
Adjustment range of current（A）
20
～
40(220V)
20
～
30(110V)
Max. no-load voltage (V)
320
Duty cycle（40℃ @ 10 minutes）
50%(220V)
50%(110V)
Note: The above parameters are subject to change with the improvement of machines.
§3 Installation
3.1 Unpacking
Identify and account for each item per the following list:
1) PCA48 Power source (with NEMA6-50 power cord and compressed air regulator/dryer)
2) NPT48 Plasma Torch (with central adaptor cable connector)
3) Earth Clamp Cable (with 200-amp clamp and 25-10 cable connector)
4) Spare Consumables (with 3 spare Electrodes and 5 spare Cutting tips)
5) Operator Manual
Inspect each item for possible shipping damage. If damage is evident, contact your distributor and / or
shipping company before proceeding with the installation.
3.2 Plasma Torch & Earth Clamp Connections
Install the NPT48 plasma torch by first removing the plastic cap on the brass machine plug. Insert the
plug into the female socket on the front panel being certain to align the collar with the pin detents. Screw
locking collar in place to secure torch.
Install the earth clamp cable by inserting the brass plug into the female socket on the front panel being
certain to align the tab with the channel and “TWIST-LOCK” into place to secure.
