Matrix 1-SERIES - Chapter 3: Serial Number Location; Serial Number Location; Chapter 4: Stepper Parts & Assembly Guides; Fasteners and Assembly Tools

4 5
CHAPTER 3: Serial number location CHAPTER 4: Stepper parts and assembly Guides
FASTENERS & ASSEMBLY TOOLS
PARTS NO. DESCRIPTION QUANTITY SKETCH
Z11
Z09
Z01
Z02
Z03
Z04
Z06
Z05
Z10
Z09
Z11
Z32
Z33
Red
Pink
Black
Blue
COLOR
OF BAG
SOCKET BUTTON HEAD BOLT
(M8 x 1.25P x 30mm)
SPRING WASHER
( 8.2 x 13.5 x 2.0T)
SOCKET CAP HEAD BOLT
(M8 x 1.25P x 60mm)
SOCKET CAP HEAD BOLT
(M8 x 1.25P x 20mm)
FLAT WASHER
( 8.2 x 13 X 1.4T)
SOCKET BUTTON HEAD BOLT
(M8 x 1.25P x 55mm)
SOCKET BUTTON HEAD BOLT
(M8 x 1.25P x 20mm)
SOCKET BUTTON HEAD BOLT
(M8 x 1.25P x 16mm)
ARC WASHER
( 8.2 x 18.0 x 1.5T)
SPRING WASHER
( 8.2 x 13.5 x 2.0T)
SOCKET BUTTON HEAD BOLT
(M8 x 1.25P x 30mm)
#5 L-TYPE (+ TYPE)
WRENCH (66L)
#6 L-TYPE
WRENCH (120L)
2
2
1
2
3
2
1
4
4
4
4
1
1
3.1 SERIAL NUMBER LOCATION 4.1 FASTNERS & ASSEMBLY TOOLS
The serial number is located in front of right shroud.
SERIAL # PL ACEMENT
