Matrix 92552 - Technical Data

11
Defective Electrical Connection Cables
Electrical connection cables often suer
insulation damage.
Possible causes are:
• Pinch points when connection cables are run
through window or door gaps.
• Kinks resulting from incorrect attachment or
laying of the connection cable.
• Cuts resulting from running over the
connecting cable.
• Insulation damage resulting from forcefully
pulling out of the wall socket.
• Cracks through aging of insulation.
Such defective electrical connection cables
must not be used as the insulation damage
makes them extremely hazardous.
Check electrical connection cables regularly
for damage.
Make sure the cable is disconnected from the
mains when checking.
Electrical connection cables must comply with
the regulations applicable in your country.
Single-phase Motor
• The mains voltage must coincide with the
voltage specied on the motor’s rating plate.
• Extension cables up to a length of 25 m must
have a cross-section of 1.5 mm
2
, and beyond
25 m at least 2.5 mm
2
.
• The connection to the mains must be
protected with a 16 A slow-acting fuse.
Only a qualied electrician is permitted to
connect the machine and complete repairs on
its electrical equipment.
In the event of enquiries please specify the
following data:
• Motor manufacturer
• Type of motor voltage
• Data recorded on the machine’s rating plate
• Data recorded on the switch’s rating plate If
a motor has to be returned, it must always be
dispatched with the complete driving unit and
switch.
Accessories
SAWDUST SUCTION REMOVAL SYSTEM
The mitre saw is equipped with a suction
connector, so that it can be connected to a
suction system. Optionally, a dust bag can also
be installed.
The hose of the suction system is fastened to
the suction connector with a hose clamp. We
recommend that you empty the bag or the
container of the suction assembly
from time to time and clean the lter.
The air ow rate of the suction system must be
at least 30 m per second.
Technical data
Saw blade ø 10"x ø 5/8", 48 T
Speed /min 4800
Swivel range 2 x 45°
Tool cutting-edge inclination 45°
Adjustments 45°, 30°, 22,5°, 15°, 0°,
15°, 22,5°, 30°, 45°
Weight kg 11.42
Cutting capacity for rip cutting
0°/0°/ 5 29/32 x 2 23/64 IN (15X6.0 CM)
45°/0° 3 11/32 x 2 23/64 IN (8.5X6.0 CM)
0°/45° 5 29/32 x 1 1/4 IN (15X3.2 CM)
45°/45° 3 11/32 x 1 1/4 IN (8.5X3.2 CM)
Drive
Motor V/Hz 120 V ~ 60 Hz
Input A 15 A
Subject to technical modications!
The height of the work piece must be at
least 3 mm.
Make sure that the work piece is always
secured with the clamping device.
Information on noise
The noise levels of the machine during
operation are as follows:
L
pA
: 99.6 dB(A) K=3 dB(A)
L
wA
: 112.6 dB(A) K=3 dB(A)
Vibration: 4.51 m/s
2
K=1.5 m/s
2
