LIST OF MAIN PART
1. Fixture A
2. Motor
3. protective brush
4.sanding plate
5. screw
6. extraction hose A
7. front handle
8.speed regulator
9. on/o switch
10. rear handle
11 Fixture B of extension bar
12. extension bar
13. hose connector
14.adapter for vacuum unit connection
15. adapter for vacuum unit connection
16. extraction hose B
17. Spanner
18. sanding sheet
ASSEMBLY
1. Fitting the hose connector
1). Align the nose at the xture A ( Fig.1) with the
hose connector(13), insert the end until the dot
fall into the slot. (Fig. 2)
2).Strip the machine by the opposite actions.
3) Fitting sanding sheets.
2. Use extension bar
1.) Loose Fixture B of extension bar (Fig.3)
2) Extend the extension bar (12), realizing the
machine’s adjustable length; (g.4)
3). tighten the xture B(1) by turning it to the
right (Fig.5)
3. Fitting front handle.
1). adjust the front handle (7)(g.6) position by
loosing the knob ;
2). Assembly the front handle (7) by tightening
the knob for easy holding(g.7)
4. Fitting sanding sheets.
Place a sanding sheet (20) in the middle of
the sanding plate(4) and press into place. The
sanding sheet has a eece coating on the
underside. The hook and loop xture on the
sanding plate secures the sanding sheet . (g.8)
5. Connect to Vacuum Cleaner
--Connect adapter (15) of the hose to the vacuum
cleaner;
OPERATION
Before use
Before making assembly, changing and
adjustment for any accessory, disconnect the tool
from the mains supply to avoid any unintentional
starting.
Please always check the mains supply voltage
before use! It must correspond with the rating
label on the appliance.
Remove any packing material and loose parts
from unit.
Check the accessories before use. It should be t
with the machine and your purpose.
Sanding Warning: Risk of injury! This tool may
only be used for dry sanding. Make sure you are
standing rmly. When working, stand on an even
surface and keep your balance, when working at
a height, stand on safe scaolding and make sure
you have a secure stance
CAREFUL. Machine damage!
