44
the box, the two poles are connected by
interconnection cord as shown in picture.
Insert part (I) into part (II), and x the two parts
by screw. The poles are egg-shaped and will only
install one way.
Assembling the working head to the
telescopic pole (A6-A7)
- Insert the connecting head for telescopic
pole (12) into the slot of working head until the
locking device (A) clicks into place.
- Fix two parts with the supplied screws.
Exchanging the working head of pole hedge
trimmer or pole chain saw (A7-A8)
- Loosen the two screws and press the locking
device (A) down using spanner.
- At the same time pull the connecting head for
telescopic pole (12) from the slot of working
head, to separate two parts away.
- Connect the needed working head (A6-A7).
WARNING: Failure to lock telescopic pole as
directed above could result in serious injury
or death.
Assembling shoulder strap (A9-A12)
- Place the karabiner (a) and harness as shown
and then insert the latch (b) into the hole.
- Attach the strap to the tting provided on the
tool and adjust the length of the strap to attain a
comfortable working position.
- Wear the shoulder strap over the left shoulder.
And keep the power unit on the right hand side
of the body.
Attention: In an emergency, pull out the latch
(b), and you can detach the machine from
you. Be extremely careful to maintain control
of the machine at this time. Do not allow the
machine to be deected toward you or anyone
in the work vicinity.
Operation
This garden tool may only be connected to
single-phase AC socket-outlet. Ensure that the
hedge trimmer)
a
h
= 2,24 m/s² Uncertainty K=1,5m/s² (For pole
chain saw)
For rear handle :
a
h
= 1,694 m/s² Uncertainty K=1,5m/s² (For pole
hedge trimmer)
a
h
= 1,654 m/s² Uncertainty K=1,5m/s² (For pole
chain saw)
Information:
- The declared vibration total value has been
measured in accordance with a standard test
method and may be used for comparing one tool
with another
- The declared vibration total value may also be
used in a preliminary assessment of exposure.
Warning:
- The vibration emission during actual use of the
power tool can dier from the declared total
value depending on the ways in which the tool is
used
- The need to identify safety measures to protect
the operator that are based on an estimation of
exposure in the actual conditions of use (taking
account of all parts of the operating cycle such as
the times when the tool is switched o and when
it is running idle in addition to the trigger time).
Assembly
WARNING:
. Stop the machine and disconnect from mains
before cleaning, checking, maintenance or
working on the machine.
. Do not connect to power supply until
assembly is complete. Failure to comply could
result in accidental starting and possible
serious personal injury.
Assembling the two parts of the telescopic
pole (A3-A5)
Before using the garden tool, a one-time
assembly is required. When removed from
