4.1 HAND GRIP FOAM REPLACEMENT
1) To loose the screws of end cap of handlebar (Figure A).
2) To take off the end cap and cut off the original foam (Figure B).
3) Using tape to seal up the handlebar tube to avoid the oil or suds into the tube (Figure C).
4) To bent and hold the end of foam then put oil or suds into the inside of foam (Figure D).
5) Push the foam to tube (Figure E).
6) Take off the tape and fix the end cap. Torque required 24 lbs/in (Figure F)
Figure A Figure B
Figure C Figure D
Figure E Figure F
