Matrix G3-MS20

12
4.3 THE SLEEVE OF PULLEY SET REPLACEMENT
1) Remove the cable fixing screw (Figures A)
2) Refer section 4.2 to remove the stopper then remove the pulley set from position tube (Fig. B)
3) Disconnect the two old tube bushings from the pulley set (Figures C & D).
4) Push another two new tube bushings in the pulley set (Figures E & F).
Figure A Figure B
Figure C Figure D
Figure E Figure F
