Matrix MG-PL62 User Manual

6
G
F
E
ENGLISH
C
B
A
C
A
C
D
1 2
Step 1 Hardware
Description Qty
A
B
C
D
Bolt (M10x100L-32L)
Washer (Φ10.2xΦ18.4)
Arc Washer (M10)
Nylon Nut (M10)
20
4
36
16
Step 2 Hardware
Description Qty
E
F
G
Bolt (M10x20L)
Spring Washer (Φ12.2x21.5)
Washer (Φ13.0x26.0)
8
8
8

Matrix MG-PL62 Specifications

General

Brand	Matrix
Model	MG-PL62
Category	Fitness Equipment
Language	English
