TOOLS REQUIRED FOR ASSEMBLY (not included)
3MM L-Shaped Allen Wrench 10MM L-Shaped Allen Wrench
4MM L-Shaped Allen Wrench 12MM L-Shaped Allen Wrench
5MM L-Shaped Allen Wrench Phillips Screwdriver
6MM L-Shaped Allen Wrench 8MM Open-End Wrench
8MM L-Shaped Allen Wrench 19MM Open-End Wrench
If any items are missing please contact your country’s local MATRIX dealer for assistance.
0 mm 10 20 30 40 50 60 70 80 90 100 110 120 130
UNPACKING
Thank you for purchasing a MATRIX Fitness product. It is inspected before it is
packaged. It is shipped in multiple pieces to facilitate the compact packaging of
the machine. Prior to assembly, conrm all the components by matching them
with the exploded diagrams. Carefully unpack the unit from this box and dispose
of the packing materials in accordance with your local laws. Exercise device must
be assembled by a trained assembly team or be pre-assembled prior to delivery.
CAUTION
To avoid injury to yourself and prevent damage to the frame components,
be sure to have proper assistance removing the frame pieces from this box.
Please be sure to install the equipment on a stable base, and properly level the
machine. Ensure a minimum clearance width of 0.6 meters (24”) for access to
and passage around MATRIX strength equipment. Please note, 0.91 meters (36”)
is the ADA recommended clearance width for individuals in wheelchairs.
TRAINING AREA
2.3 M
(91.7”)
1.1 M
(43.5”)
FREE AREA
0.6 M (2 FT)
WIDE PATH
