CHAPTER 7: MX-A5x specifications and assembly steps
7.2 MX-A5x ASCENT TRAINER FASTENERS & ASSEMBLY TOOLS
01 6mm ALLEN WRENCH
01 PHILLIPS DRIVER
01 OPEN WRENCH (#13)
QTY PART # SKETCH DESCRIPTION NOTES
04 Z01 HEX SOCKET HEAD CAP (M8 x 15L)
08 Z02 HEX SOCKET HEAD CAP (M8 x 20L)
06 Z03 CROSS TRUSS HEAD (M5 x 10L)
04 Z04 HEX SOCKET HEAD CAP (M8 x 65L)
02 Z05 HEX SOCKET HEAD CAP (M8 x 55L)
02 Z06 FLAT WASHER (8.2 x 16.0 x 1.0)
02 Z07 NYLON NUT (M8 x 1.25L)
04 Z08 AXLE
04 N51 CROSS TRUSS HEAD (M5 x 8L) Included in console
02 B28 HEX SOCKET HEAD CAP (M8 x 30L)
