Matrix PEL-8000 Series User Manual

5
3.3 front and rear panel introduction
PEL-8000 series electronic load front panel as shown below
Figure 3.2 Front panel
1
The top half of the panel is the black VFD display and knob
2
The lower part of the panel from left to right are 0-9 numeric keys and ESC exit key, function key, up and down
move key and Enter key, input and output terminals.
PEL-8000 series electronic load rear panel as shown below
Remote measurement terminal, trigger input and output interface
Multi-function communication interface, GPIB, RS232, RS425, USB transfer
