6.1 USING ENGINEERING MODE
CHAPTER 6: ENGINEERING MODE
To enter Engineering Mode, hold the LEVEL UP and DOWN keys for 3-5 seconds until Manager Mode appears on the middle LED display.
Press the LEVEL UP or DOWN key to scroll to Engineering Mode. Press ENTER to go into Engineering Mode.
CODE DEFAULT OPTIONS DESCRIPTION
Disable Errors No Yes or No No - Shows A-C class error codes. Yes - Shows only C class error codes.
Speed Units Mile Mile or Kilometer Set for Mile or Kilometer.
Machine Type R5x-05 H5x-05, U5x-05,
R5x-05, H5x-04,
U5x-04, R5x-04,
E5x-02, E5x-03
The Hybrid bike console should be set to U5x-05.
Power Save Time 30 Seconds 30-60 Seconds Power saving time for the self powered frame.
Pause Time 30 Seconds 15 - 120 Seconds For non self powered frames only. Not used on this model.
Serial Number N/A N/A Serial Number input is available for both the Console and Frame. Use the number
keys and UP / DOWN LEVEL keys to enter Engineering Mode. Due to the limited
LED characters, 2 layers are used to enter the serial number. First Layer:
- PPPPP V
- PPPPP is the product name.
- V is the version. If the version is A, just leave this blank.
Second Layer
- YY MM nnnnn.
- YY is the year (11, 12).
- MM is the month (e.g. 08, 09, 10).
- nnnnn is the actual serial number.
Use the UP / DOWN LEVEL keys to navigate the layers and the number keys to
input the serial number. The product name is dependent on the Machine Type
setting.
For example, the console is EP612 with version A and the manufactured date is
2012.08 with 98765. The frame is RB307 and the manufactured date is 2013.06
with 12345. Their serial numbers are:
Console SN: EP612 1st layer, 120898765 2nd layer.
Frame SN: RB307 1st layer, 130612345 2nd layer.
Club ID N/A N/A This sets the club ID for clubs using Asset Management.
ErP Mode (Sleep
Time)
Off Off or On (1-30
Minutes)
If there is no use of the machine over a period of time, the console LEDs will turn
off (go into ErP mode).
Audio Source Off Off / TV / PC TV /
Remote TV
Manual setting that sets which outside TV will have audio through the console
audio ports.
AM System WIFI WIFI / RF Radio To select AM output device by WIFI or RF Radio.
Volume Control TV/ PCTV:
Output:13
1~ 32 Controls the default TV volume for entertainment wired through the C-Safe port.
a. Input Default (DF : 15 / Range : 1 ~ 15)
b. Max Default (DF : 32 / Range : 1 ~ 32)
c. Output Default (DF : 13 / Range : 1 ~ Max)
Remote TV support a / b / c item. TV and PCTV only support c item.
REMOTE TV
Output:13
1~ 32
REMOTE TV
Input:15
1~ 15
