Matrix R5X-05 - Front Stabilizer Replacement

53
CHAPTER 9: PART REPLACEMENT GUIDE
9.22 FRONT STABILIZER REPLACEMENT
1) Remove the 4 screws holding the rear stabilizer to the frame (Figures A & B). .
2) Remove the front stabilizer (Figure C).
3) Reverse Steps 1-2 to install a new front stabilizer.
FIGURE A FIGURE B
FIGURE C
