CHAPTER 10: ROWER-02 SPECIFICATIONS AND ASSEMBLY GUIDE
10.3 ASSEMBLY INSTRUCTIONS - CONTINUED
STEP 5
STEP 6
ASSEMBLY
COMPLETE!
M
J
L
Red Hardware Pack
Description Qty
J
K
L
M
Bolt
Flat Washer
Nut
Arc Washer
3
2
1
2
Note:
Tighten hardware from step 5
using the Torque Value:
39.2 Nm / 29 ft-lb
Black Hardware Pack
Description Qty
N Bolt 2
N
Rotate console
mast up 30 degrees
