Matrix T1XE-04 User Manual

65
9.15 CONSOLE FRAME REPLACEMENT - CONTINUED
7) Remove the console frame from the handlebar frame (E).
8) Reverse Steps 1-7 to install a new console frame.
9) Test the treadmill for function as outlined in Section 9.21.
FIGURE E
CHAPTER 9: PART REPLACEMENT GUIDE
