25
STEP 3 | PREMIUM KIT ASSEMBLY INSTRUCTIONS & NOTES
PART 9: PREMIUM KIT ASSEMBLY
1. Remove and discard hole caps using cau-
tion not to scratch the paint.
2. Attach plug to Rep Counter.
3. Assemble Towel Hook (3P) and Rep Counter
(2P) using the M8 X 35L SHC bolts provided.
4. Torque bolts to 17 N-m/147 in-lbs.
Rep Counter wires must be
routed through the center of
the Towel Hook
Rep Counter
ASSEMBLY
To Next Page
